Your Professional Plate And Sheet Manufacturer



Lork Group specializes in supplying sheet and plate stock in five materials: nickel alloys, cobalt alloys, titanium alloys, precision alloys, and stainless steel. We maintain inventory standards in accordance with ASTM, AISI, AMS, JIS, GB, and other relevant standards. These sheets are commonly used in aerospace, medical, and industrial applications. We stock plates in thicknesses ranging from 0.3mm to 150.0mm and widths from 1000mm to 3000mm, with custom lengths available. Most importantly, we support third-party testing and have extensive customer experience verifying our sheet and plate stock, ensuring peace of mind in your selection and reliable delivery!

  • Commercially Pure Titanium Grade 2 (TA2)

    Grade 2 (TA2) Titanium is a versatile material offering an exceptional balance of strength, weight savings, and corrosion resistance. Its adaptability in welding, machining, and heat treatment makes

  • Hastelloy C-276 Nickel Alloy

    Hastelloy C276 is a nickel-molybdenum-chromium-tungsten alloy with added tungsten. C276 has good machining properties and also has excellent corrosion resistance in some of the harshest environments.

  • Custom 450 Plate

    Custom 450 (UNS S45000) is a martensitic precipitation-hardening stainless steel that offers high strength, good toughness, and excellent corrosion resistance. Its mechanical properties can be

  • Nitronic 50 Plate

    Nitronic 50 (UNS S20910 / XM-19) is a nitrogen-strengthened austenitic stainless steel that offers a combination of high yield strength, excellent resistance to chloride-induced corrosion, and low

  • Custom 465 Plate

    Custom 465 precipitation-hardening stainless steel (UNS S46500) is supplied in the solution-annealed condition (hardness ≤330 HBW) and is available as plates or sheets with thicknesses ranging from

  • Haynes 230 Sheet(AMS 5878)

    AMS 5878 specifies the requirements for Haynes 230 alloy in sheet form, including chemical composition, mechanical properties, heat treatment, testing methods, and quality assurance to meet aerospace

  • Nitronic 60 Plate(Alloy 218, N60)

    We offer supply and custom procurement services for Nitronic 60 (UNS S21800) plates. Standard specifications typically range from 2–50 mm in thickness and 600–1000 mm in width; actual available

  • Ti-13V-11Cr-3Al Titanium Alloy Sheet & Plate

    Ti-13V-11Cr-3Al titanium alloy sheet is a heat-treatable β-titanium alloy suitable for aerospace structural components and other lightweight, high-strength applications. Delivery conditions depend

  • ASTM F139 316LVM Sheet & Strip

    ASTM F139 316LVM medical-grade stainless steel sheet&strip (UNS S31673 / 1.4441) conforms to ASTM F139 / ISO 5832-1 standards. It is supplied in either a solution-annealed condition or a cold-rolled

  • UNS N08810 Incoloy 800H Plate / Sheet

    Incoloy 800H (UNS N08810) is an austenitic heat-resistant alloy sheet/Plate developed from Incoloy 800 by controlling the carbon content (0.05–0.10%) and grain size (ASTM grade 5 or coarser). It is

  • Multimet Alloy N155 Industrial Gas Turbine Plate

    Multimet N155 sheet metal is a high-temperature iron-nickel-cobalt-based alloy designed for industrial gas turbines and heat-resistant equipment. It is suitable for specific combustion system

  • ASTM F688 MP35N Plate, Sheet, And Foil

    MP35N plates, sheets, and foils are primarily used to manufacture surgical implant components that demand high strength, corrosion resistance, and fatigue performance. Specific applications include

First 1234567 Last



Custom Plate and Sheet

We offer custom plate and sheet fabrication solutions to suit your project needs. Customizable Options:

1. Material Type:

We offer a wide range of materials for you to choose from.



2. Thickness:

Customizable upon request.



3. Sheet Size:

Customizable upon request.



4. Surface Texture:

We offer a wide range of surface texture options, including brushed, matte, and mirror finishes. All texture effects can be customized upon request.



5. Surface Coating:

We offer a wide range of surface coating options, including zinc plating, chrome plating, and nickel plating. All coating processes can be customized upon request.

Nimonic PK33 Alloy Sheet



Types of Plate and Sheet



1. Stainless Steel Sheet

A stainless steel sheet is essentially a low-carbon steel that contains chromium at 10% or more by weight. It is this addition of chromium that gives the steel its unique stainless, corrosion-resisting properties.



2. Nickel Alloy Sheet

Nickel alloy sheet is a metallic alloy composed primarily of nickel with varying percentages of other elements, like chromium, molybdenum, titanium, and iron. Nickel alloys are used in various applications because they offer excellent corrosion resistance and strength.



Plate and Sheet Specification



Dimensions

EN, DIN, JIS, ASTM, BS, ASME, AISI

Width

1000 MM TO 2500 MM

Thick

0.5 MM TO 200 MM

Length

100MM TO 600MM

Form

Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange)

Finish

Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)

Hardness

Soft, Hard, Half Hard, Quarter Hard, Spring Hard, etc.



Plate and Sheet Chemical Composition



Element

Content (%)

Ni

30-35

C

0.1 max

Fe

39.5 min

Si

1.0 max

Mn

1.5 max

S

0.015 max

AI

0.15-0.60

Ti

0.15-0.60

Cu

0.75 max

Cr

19-23



Plate and Sheet Mechanical Properties



Properties

Metric

Imperial

Tensile strength (precipitation hardened, value at room temperature)

900 MPa

131000 psi

Yield strength (@strain 0.200%, precipitation hardened, value at room temperature)

450 MPa

65300 psi

Elongation at break (precipitation hardened)

28%

28%



Plate and Sheet Thermal Properties



Properties

Metric

Imperial

Thermal expansion coefficient (@21-100°C/69.8-212°F)

13.8 µm/m°C

7.67 µin/in°F

Thermal conductivity

11.72 W/mK

81.34 BTU in/hr.ft².°F



Plate and Sheet Material



Superalloys

Inconel

Hastelloy

Monel

Incoloy

Inconel 625

Inconel 718

Inconel 600

Inconel X750

Inconel 601

Inconel 617

Inconel 690

Inconel 738LC

Inconel 713C

Inconel 602CA

Inconel 725

Inconel 686

Inconel 751

Hastelloy C276

Hastelloy C22

Hastelloy X

Hastelloy C4

Hastelloy B2

Hastelloy G30

Hastelloy C2000

Hastelloy B3

Hastelloy G

Hastelloy N

Hastelloy S

Hastelloy W

Hastelloy G3

Monel 400

Monel k500

Monel r405

Monel 404

Monel 401

Monel 450

Incoloy 800

Incoloy 825

Incoloy 925

Incoloy 800ht

Incoloy 909

Incoloy 901

Incoloy 840

Incoloy 20

Incoloy 28

Incoloy 330

Incoloy 907

Incoloy 945

Incoloy 903

Incoloy A286

Haynes Alloy

Nimonic Alloy

Other Alloy

Haynes 230

Haynes 282

Haynes 188

Haynes 214

Haynes 556

Haynes 242

Haynes 25

Haynes 233

Haynes 244

Haynes 263

Nimonic 90

Nimonic 80a

Nimonic 75

Nimonic 115

Nimonic 901

Nimonic 105

Nimonic 263

Alloy 42

Alloy 45

Invar 42

Invar 36

Kovar

Maraging 250

Maraging 300

Maraging 350

MP159

Rene 41

Waspaloy

MP35N



Stainless Steel

Duplex Stainless Steel

Precipitation Hardening Stainless Steel

300 Series Stainless Steel

Other Stainless Steel

UNS S31803

UNS S32750

UNS S32205

UNS S32760

CD4MCuN

zeron 100

Ferralium 255

17-4PH

17-7PH

PH13-8mo

15-5PH

PH 15-7mo

AISI 316

AISI 316L

AISI 304

AISI 304L

AISI 301

AISI 309

AISI 310

AISI 310S

AISI 321

AISI 306

AISI 347

AISI 347H

Nitronic 30

Nitronic 40

Nitronic 50

Nitronic 60

254SMO

AL-6XN

904L Stainless Steel



Plate And Sheet Common Heat Treatment Methods



Quenching and Tempering:

This two-step process boosts strength and toughness. The steel is heated and quickly cooled (quenching), then reheated to a lower temperature (tempering) to reduce stresses and refine its structure.



Annealing and Normalizing:

Annealing heats the steel to a set temperature and cools it slowly to improve ductility. Normalizing heats the steel above its critical temperature and air-cools it to refine the grain structure.



Application of Plate and Sheet

Construction

Military

Ship construction

Pressure vessels

Shipping

Oil and gas

Household appliances

Automotive Industry

Road Work

Quality Inspection Procedures

Spectrometer
Spectrometer
Ultrasonic Testing
Ultrasonic Testing
Stress Corrosion Testing
Stress Corrosion Testing
Microcopy
Microcopy
Mechanical
Mechanical
Eddy Current Test
Eddy Current Test
Heat Treatment Furnace
Heat Treatment Furnace
Corrosion Test
Corrosion Test
Hydraulic Test
Hydraulic Test
Metallographic Test
Metallographic Test

FAQ

Q: What is a plate and sheet?

A: The difference between a metal sheet and a metal plate can be defined by thickness. If the thickness of the metal is ¼" (6mm) or more, then it is considered a plate. Plate thickness is typically measured in inches. If the thickness is less than ¼" (6mm), it is considered sheet.

Q: How are plates and sheets manufactured?

A: They can be produced through processes like rolling, extrusion, or forging.

Q: What determines the strength of a plate or sheet?

A: The greater the carbon content in the steel plate, the more rugged and durable it becomes. High carbon steel plates are commonly utilized in applications where additional strength is required, such as for bridges, I-beams, and other large-scale projects.

Q: What surface finishes are available for plates and sheets?

A: Options include polished, brushed, textured, and painted.

Q: How are the dimensions of plates and sheets measured?

A: Length, width, and thickness are typically measured using specific measuring tools.

Q: Is 3 16 a plate or sheet?

A: A 3/16" steel plate is commonly used in structural applications, manufacturing, fabrication, and repair projects, and is an ideal choice for constructing bridges and buildings, cams, welding, and bending.

We're well-known as one of the leading plate and sheet manufacturers in China. Please feel free to buy cheap plate and sheet for sale here and get pricelist from our factory. For price consultation, contact us.
